Equipment Installation Manual,

GDC31 Roll Steering Converter

SLIDE LATCH ASSEMBLY

Assemble the slide latch mechanism, part number P10219 or P10053, onto the mating connector as

pictured using the hardware supplied with the slide latch.

SLIDE LATCH

SCREW

CONNECTOR

FLAT WASHER

NUT

LOCK WASHER

1049-2510-01 G.doc

1049-2510-01

Rev G Page 29 of 47
