Equipment Installation Manual,
GDC31 Roll Steering Converter
OPTIONAL EQUIPMENT
Certain installations require the use of an Isolation Coupler assembly. Refer to the applicable installation
drawings later in this manual for usage. This assembly is sold separately and comes with installation kit.
Part Number Description
1049-4801-01 Isolation Coupler
1049-4200-50 Installation Kit, Isolation Coupler
Complete installation kits are available separately under kit part number 1049-4200-50. Individual
pieces are available under the part numbers shown. Contact DAC International sales to place orders.
Part Number Description Qty
1049-4200-50 Installation Kit, Isolation Coupler
M24308/2-2F Connector, Receptacle, 15 pin D-Sub 1
M39029/63-368 Socket, Crimp Style, female 15
P10053 Slide Latch Kit 1
P10067 Backshell, 15-Pin D-Sub 1
1049-2510-01 G.doc
1049-2510-01
Rev G Page 8 of 47
