Equipment Installation Manual,
GDC31 Roll Steering Converter
SPECIFICATIONS:
Physical:
The GDC31 attaches to the airframe via four mounting holes. See the paragraph titled GDC31 Outline
Drawing for further details.
RSC LRU
Height.................................................1.25”
Width..................................................5.22” (Includes mounting flange)
Depth..................................................3.54”
Weight................................................0.4 lb.
The Isolation Coupler (optional) attaches to the airframe via four mounting holes. See the paragraph
titled Isolation Coupler Outline Drawing for further details.
Height.................................................1.25 in
Width..................................................4.5 in (Includes mounting flange)
Depth..................................................2.41 in”
Weight................................................0.2 lb.
Annunciator
Height.................................................0.753”
Width..................................................0.753” (Includes mounting flange)
Depth..................................................1.99”
Weight................................................0.05 lb.
Electrical:
Input Voltage .....................................14 / 28 VDC (10Vdc – 32Vdc operational)
Input Current......................................0.1 Amp maximum at 28 VDC
Annunciator lamp current..................0.04 Amp at 28 VDC, 0.08 Amp at 14 VDC
