F-02. Division (Minimum display unit set up)
(Standard setup value: 1)
Display data
Setting
Remark
1
Displayed In 1
(0, 1, 2, 3, 4 …….)
CH1, CH2
Individual setup
2
Displayed in 2
(0, 2, 4, 6, 8 …….)
5
Displayed in 5
(0, 5, 10, 15 …….)
10
Displayed in 10
(0, 10, 20, 30 …….)
20
Displayed in 20
(0, 20, 40, 60 …….)
50
Displayed in 50
(0, 50, 100, 150 …….)
F-03. Display filter (Display speed set up)
(Standard setup value: 8)
Display data
Setting
Remark
0
No filter
Only CH1
4
Average time 1/8 sec
8
Average time 1/4 sec
16
Average time 1/2 sec
32
Average time 1 sec
F-04. Hold mode
(Standard setup value: 1)
Display
data
Setting
Remark
0
Sample Hold
: To hold the display value at the time of Hold signal
input.
CH1
setup
1
Peak Hold
: To hold the maximum value of display values during
Hold signal input.
2
Absolute Peak Hold
: To hold the maximum absolute value of display values
during Hold signal input.
F-05. Comparision mode (Comparision output mode set up)
(Standard setup value: 0)
Display data
Setting
Remark
0
Decision mode
: Relay RY1, RY2, RY3, RY4 output
CH1, CH2
Individual
setup
1
High limit mode
: Relay RY1, RY2, RY3, RY4 output
2
Low limit mode
: Relay RY1, RY2, RY3, RY4 output
