dacell DN-130L User Manual

19
F-06. Hysteresis
(Standard setup value: 00)
Display data
Setting
Remark
00
00
: Hysteresis – not used
CH1,CH2
Individual
setup
~
99
01 ~99
: Hysteresis – used(Decision mode is not applied)
F-08. DAC capacity (Analog Outupt value set up)
(Standard setup value: 10000)
Display
data
Setting
비고
-19999
Analog output capacity set-up
<Setting value & output>
Setting
value
Voltage output(±10V)
Current output(4~20mA)
Display value
output
Display value
+10000
-10000
-10V
-10000
-
0
0V
0
4mA
+10000
+10V
+10000
20mA
-10000
-10000
+10V
-10000
20mA
0
0V
0
4mA
+10000
-10V
+10000
-
1
CH1, CH2
Individual
setup
~
+99999
F-09. ID Number (Communication Device Number set up)
(Standard setup value: 00)
Display data
Setting
Remark
00
00
: Device number is not set-up(Stream mode:always transmit data )
CH1
setup
~
32
01~32
: Device number is set-up(Command mode:Transmit data by command)
CH2 ID Number : CH1 ID Number + 1
F-10. Baud rate & Print (Communication Speed set up)
Display data
Setting
Stream mode
Command mode
비고
2.40
2400 bps
O
O
CH1
setup
4.80
4800 bps
O
O
9.60
9600 bps
O
O
19.20
19200 bps
O
X
38.40
38400 bps
O
X
57.60
57600 bps
O
X
