dacell DN-30W User Manual

47
2) Modbus RTU protocol (R/O : Read only, W/O : Write only. R/W : Read & Write)
Address
(Decimal)
Func
code
Description Value Type Format
Device Function Value
0000 0×04 F-00 Decimal Point 0 ~ 3 R/O UNIT16
0001
0×04 F-01 Division 1 ~ 50 R/O UNIT16
0002
0×04 F-02 Display Filter 1 ~ 100 R/O UNIT16
0003
0×04 F-03 Hold Mode 0 ~ 3 R/O UNIT16
0004
0×04 F-04 BCD BUSY time 50 ~ 1000(x1ms) R/O UNIT16
0005
0×04 F-10 Auto Zero Tracking 0 ~ 99 R/O UNIT16
0006
0×04 F-11 Auto Zero Tracking Time 0 ~ 50 (x100ms) R/O UNIT16
Address
(Decimal)
Func
code
Description Value Type Format
0007 0×04 F-12 Auto Zero during operation 0 ~ 1 R/O UNIT16
0008
0×04 F-13 Base offset -19999 ~ +99999 R/O INT32
0009
0010 0×04 F-20 Comparison Mode 0 ~ 3 R/O UNIT16
0011
0×04 F-21 Hysteresis 0 ~ 99 R/O UNIT16
0012
0×04 F-30 DAC mode
0 ~ 7
※
R/O UNIT16
0013
0×04 F-31 DAC capacity 0 ~ 99999 R/O INT32
0014
0015 0×04 F-32 DAC Speed 0 ~ 1 R/O UNIT16
0016
0×04 F-40 ID Number 0 ~ 255 R/O UNIT16
0017
0×04 F-41 Baudrate
0 ~ 6
※
R/O UNIT16
0018
0×04 F-42 Protocol 0 ~ 1 R/O UNIT16
0019
0×04 F-50 Display reverse mode 0 ~ 2 R/O UNIT16
0020
0×04 F-51 Force Unit 0 ~ 4 R/O UNIT16
0021
0×04 F-52 Key Disabling 0000 ~ 1111 R/O UNIT16
Measurement
0030
0×04 Net Display Value -19999~+99999 R/O INT32
0031
0032 0×04 Relay Setpoint output
0×0001 : Relay 1
R/O UNIT16
0
×0002 : Relay 2
0
×0004 : Relay 3
0
×0008 : Relay 4
0
×0010 : Relay 5
Option
0
×0020 : Relay 6
