dacell DN-30W User Manual

4
3. Specification
Spec. Model DN-10W DN-50W DN-30W DN-70
Available sensor Strain Gauge sensor
PROXIMITY
SENSOR
Strain Gauge
sensor
SIGNAL 0.5 ~ 3mV/V pulse 0.5 ~ 3mV/V
EXCITATION DC 5V 70mA 12V DC 5V 70mA
Upper limit Display -19999 ~ +99999
60pulse/1circle
:0~13000 13kHz
-19999 ~
+99999
A/D Converter
24bit 200
times /s
24bit 1000
times /s
24bit 200
times /sec
D/A Converter 16bit
Temperature
Characteristic
Zero ±10ppm/℃
Span ±10ppm/℃
Measured value display 7 segment 5 Digit, Height 14mm (DN -70 Height 8mm )
Status display LED Red LED 6PCS
Red LED
5PCS
Key Switch 4pcs
Comparison output 4 Relay 4 Relay
Contact Capacity AC 250V 3A (more than 100,000)
Analog out DC 0~±10V or 4~20mA (Selective use)
Op ti o n
Temperature Range -10℃~ 60℃, 80% less than 80% RH (no dewing.)
Sizes 96 × 48 × 128 mm (W × H × D)
48 × 48 ×
128mm
Panel cutting size 91.5 × 44.5 mm
45.5 × 45.5
mm
Weight : about 500g : about 280g
Power supply AC 90 ~ 240V 8VA (DC24V 0.3A)
DC24V 0.2A
Option
OP-02 : RS232C (basic installation), OP-
03 : RS485
Interface
OP-01 : Parallel BCD output
OP-10 : Power DC24V 0.3A
OP-06 DC 0~±
10V or 4~20mA
OP-14: Signal 5mV/V
OP-15: Signal10mV/V
