dacell DN-30W User Manual

5
Spec. Model
DN-20W
DN-25W
DN-27W
DN-80
Available sensor
Voltage, current
sensor
Potentiometer
HBT(Half type)
(Option : LVDT)
Differential
trans torque
sensor
Potentiometer
SIGNAL
DC0~10V or 4~20mA
(Option : ±10V)
AC0~2Vrms 0.5~2mV/V DC0~10V
EXCITATION
DC10V or 24V 60mA
(Option : ±15V
60mA)
AC2Vrms 5kHz DC5V 70mA
MAX. Display
-19999 ~ +99999
A/D Converter 24bit 200times/sec
D/A Converter
16bit
Temperature
Characteristic
ZERO
0.5㎶/℃
SPAN
50pm/℃
Measured value
display
7 segment 5 Digit, Height 14mm (DN -70 Height 8mm )
Key Switch 4 PCS
Status display LED
Red LED 6PCS
Red LED 5PCS
Comparison output
4 Relay 3 Relay
Contact Capacity Contact Capacity AC250V 3A (More than 100000)
Analog out DC0~10V or 4~20mA DC0~±10V or 4~20mA Option
Temperature
range for use
-10℃~ 60, >80% RH (No dewing)
Sizes
96 × 48 × 128 mm (W × H × D)
48×48×128 mm
(W×H×D)
Panel cutting size
91.5 × 44.5 mm 45.5 × 45.5 mm
Weight
About 500g About 280g
Power supply
AC 90 ~ 240V 8VA (Option : DC24V 0.3A) DC24V 0.2A
OPTION
OP-02 : RS232C (basic installation), OP-03 : RS485 Interface
OP
-01 : Parallel BCD output
OP
-10 : Power DC24V 0.3A OP-06 : Analog output
DC0~±
10V or 4~20mA
OP
-12:sensor input ±15V
OP
-13:sensor signal ±10V
OP-11 : LVDT -
