0×0040 : Relay 7
0
×0080 : Relay 8
Device Configuration
4000 0×06 External Input Command
0×0001 : ZERO
W/O UNIT16 0×0002 : Hold set
0×0004 : Hold reset
4001 0×03
Relay Setpoint 1 -19999~+99999 R/W INT32
4002
0×10
4003
0×03
Relay Setpoint 2 -19999~+99999 R/W INT32
4004
0×10
4005
0×03
Relay Setpoint 3 -19999~+99999 R/W INT32
4006
0×10
Address
(Decimal)
Func
code
Description Value Type Format
4007 0×03
Relay Setpoint 4 -19999~+99999 R/W INT32
4008
0×10
4009
0×03
Relay Setpoint 5
Option
4010
0×10
4011
0×03
0×10
Relay Setpoint 6
4012
4013
0×03
0×10
Relay Setpoint 7
4014
4015
0×03
0×10
Relay Setpoint 8
4016
Fuction code Command Name Device Address
03 (0x03)
Read Holding Regigters 4001 (0x0FA1) ~ 4016 (0x0FB0)
04 (0x04)
Read Input Regigters 0000 (0x0000) ~ 0032 (0x0020)
06 (0x06)
Preset Single Regigter 4000 (0x0FA0)
16 (0x10)
Preset Multiple Regigters 4001 (0x0FA1) ~ 4016 (0x0FB0)
※ Reference
Description Value 0 1 2 3 4 5 6 7
DAC mode (0012)
b_05v b_10v b_02A b_42A U_05v U_10v U_02A U_42A
Baudrate (0017)
2.40 4.80 9.60 19.20 38.40 57.60
