daCor builT-in refrigeraTor serviCe manual
Tool Requirements
Tape measure
Level
Stud finder
Drill with various bits
Socket set
Utility knife
Magnetic extended screwdriver
Phillips screwdriver
Torx Bit
Cardboard, carpet remnant, or other
protective material for flooring
Steel Hanger Strap
Installation Checklist
INSTALLER
Doors
Handles are solidly attached to doors.
Doors seal completely to refrigerator cabinet.
Assure correct door handle alignment. Frame models.
Assure doors seals are not pinched.
Do not drive screws/sharp objects into the door.
Leveling
L Brackets are secure to 2x4 wood block.
Stabilizing legs are against floor. Cabinet is secure.
Toe kickplate is properly attached to refrigerator and
aligned with floor.
Ice Maker
Water supply to refrigerator is turned on and lines
flushed.
Water leaks are not present at connection between
household water supply and refrigerator.
Ice maker arm is down for ice production.
PuriClean® Ice and Water Filtration System is
installed correctly, if applicable.
Purge water from the fountain on dispenser models.
•
•
•
•
•
•
•
•
•
•
•
□
□
□
□
□
□
□
□
□
□
□
□
□
Preparing the Space
Make sure the opening where the unit will be
installed is properly prepared for “Cut Out”
dimension. Check placement for electrical outlet
and water line. (Fig. 1 on page 1-25)
Page 1-24
Installation Instructions
daCor builT-in refrigeraTor serviCe manual
WARNING
Electrical Connection: This appliance is
designed to operate on a normal 115 volt,
15 amp, 60 cycle line. There should be
a separate, grounded circuit serving this
appliance only. Do not use an extension cord.
Do not use any device that will alter the
electrical performance of this appliance. For
the placement of the electrical outlet refer to
Fig. 1 on page 1-25.
*Do not use a ground fault
circuit interrupter.
NOTE
For the door to open properly, it must be able
to open at least 90 degrees. For installation in
a corner, a 2" filler strip is required to ensure
the 90 degree opening. The floor under the
refrigerator is to be level with the surrounding
floor. To protect the floor when moving the
refrigerator, place cardboard, or preferable a
carpet remnant (backing up) on the floor.
