daCor builT-in refrigeraTor serviCe manual
Uncrating the Unit
Uncrate the unit. Remove the lower shipping bolts and brackets. Slide the
unit off of the crate base. Remove and save the lower kickplate, anti-tipping
brackets and mounting hardware. (Fig. 2a) Remove the grille, this will help
when moving the unit. (Fig. 2b)
3/8"
OR
TOOLS NEEDED
REMOVE
KICKPLATE
REMOVE
SCREWS
MAIN POWER SWITCH
GRILLE PANEL
Water Line Installation
Connect the water supply to the water valve.
Turn the water on and check for leaks.
Plug the unit in. (Fig. 3)
Leveler Wheels
Water Valves
Fig. 2a Fig. 2b
Fig. 3
