Page 8
ERC REPLACEMENT
1. Remove top frame
2. Remove control panel cover
3. Disconnect wire harnesses and membrane harness
4. Remove 4 nuts on each corner of ERC - pull off ERC
5. Replace ERC - making sure new ERC is centered on studs when placing
**Take care not to tear oven light ribbon when plugging and unplugging
BULL NOSE REPLACEMENT
1. Remove top frame
2. Remove control panel cover
3. Remove the two screws that are located on the far right and far left
of the backside of the bullnose
A
Figure 18-1
Figure 18-1 shows the ERC (Part Number 62707)
from behind the control panel cover.
