Daedong 3F183T - FUEL Injection SYSTEM

4
-7
MAINTENANCE
4
Never crank the engine to run
the high pressure pump for
bleeding.
•
CAUTION
FUEL INJECTION SYSTEM
(1) Fuel Tank (2) Pre-Filter (Only 4 Cylinder) (3) Main Filter (4) Injection Pipe
(5) Injector (6) Over low Pipe (7) Common Rail (8) Fuel Cooler
(9) High Pressure Pump
TE4O509A
