SPECIFICATIONSEX35(C)/EX40(C)/EX45(C)/EX50(C)
3
3
-
3
3
-
2
SPECIFICATIONSEX35(C)/EX40(C)/EX45(C)/EX50(C)
B
C
D
A
2
F
A
1
E
2
E
1
CABIN MODEL
H11O302a
※A1: Overall length including weight
A2: Overall length excluding weight
E1: Front wheel tread
E2: Rear wheel tread
※These dimensions are measured with the standard tires installed to the CABIN model tractor.
ITEM
MODEL
EX35(C ) EX40(C) EX45(C)/50(C)
1. Overall length (A1) 3,615 (142.3) 3,650 (143.7)
2. Overall length (A2) 3,280 (129.1) 3,410 (134.2)
3. Overall width (B)
1,565 (61.6) 1,625 (63.9) 1,760 (69.3)
4. Overall height (C)
2,425 (95.5) 2,455 (96.7) 2,485 (97.8)
5. Wheel base (D)
1,767 (69.5) 1,880 (74.0)
6. Tread (E1)
1,245 (49.1) 1,248 (49.1) 1,365 (53.7)
7. Tread (E2)
1,237 ~ 1,347
(48.7~53.0)
1,262~1,490
(49.7 ~ 58.6)
1,370~1,515
(53.9 ~ 59.6)
8. Ground clearance (F) 365 (14.3) 375 (14.7) 405 (15.9)
mm (in.)
