12
<FUEL METER>
The fuel meter indicates the gasoline level
inside the fuel tank.
Gasoline should be put in the fuel tank as
soon as possible if the needle is resting in
the red area.
FUEL TANK CAPACITY : 7.1
ℓℓ
((EEUU22 ::66..88ℓℓ))
RESERVE FUEL CAPACITY : 1.2
ℓℓ
<SPEEDOMETER>
Indicates driving speed. Keep the law
speed limits to ensure safe operation.
<ODOMETER>
Indicates total distance in kilometers
travelled by the vehicle.
<FUEL WARNING LAMP>
If the gasoline is low, the fuel warning
lamp will turn on.
If the warning lamp is turn on, quickly fill
the fuel tank.
<WINKER INDICATOR>
When the winker switch is operated, the
winker indicator flashes in union with the
flashing of the turn signals.
EMS(Engine Management System)is
equipped with a self-diagnosis function in
order to ensure that the engine control
system is operation normally.
If this function detects a malfunction in the
system, the malfunction indicator lamp
immediately operates.
It gives the rider that malfunction has
occurred in the system.
Normally, the malfunction indicator lamp
illuminates for 3 seconds when the main key is
turned on.
If the malfunction indicator lamp does not
come on under these conditions, the
malfunction indicator lamp may be
defective.
After 3 seconds, the malfunction indicator
lamp off automatically. However, the MIL
blinks continuously, check the EMS
system. If you are not able to check the
EMS system, contact your daelim dealers.
The EMS takes fail-safe function, it enables
to drive only temporary by starting even on
conditioned.
METER READING AND USAGE
WARNING AND INDICATOR LAMPS
METER
SPEEDOMETER
DIRECTION INDICATOR LAMP
HIGH BEAM INDICATOR
ODOMETER
