37
<REMOVAL>
① Loosen the 6 washer screws and 1
flange bolt, and remove the tube clip
and air cleaner case cover.
② Inspect the air cleaner element.
③ If the air cleaner element is
excessively dirt or damaged, replace it
with a new one.
●
Do not use screw driver or other metal
parts to remove the fuse, as short
circuit can be occurred to cause
damage to electric system.
●
Do not use a fuse having a larger
voltage, as the wire can become
overheated and damaged.
●
When replacing any of the electrical
parts (lights and gauges), be sure to
replace them with the recommended
parts. Using different parts can lead to
the fuses burning out or damage to the
battery.
●
When washing the vehicle, take
special care not to allow to be splashed
in the area of the fuses.
AIR CLEANER ELEMENT INSPECTION
●
If the air cleaner element is
inadequately assembled, dust and
other waste materials can directly
enter the engine. This results in
increased cylinder wear and reduced
power, and reduced durability of the
engine.
●
When washing the vehicle, be
careful not to allow water to get into
the air cleaner. Difficulties in
starting the engine may result if this
happens.
●
If the engine start is failed during
rain or after driving across water
pool, check to see if the water is
infiltrated in the air cleaner and clean
it.
●
Do not drive in the flooded area. If
the water enters the air cleaner or
engine, the vehicle may be subjected
to the rear-end collision due to the
power failure.
AIR CLEANER ELEMENT
AIR CLEANER CASE
AIR CLEANER COVER
