38
A rubber boots is assembled on the cable
to protect the inner cable.
Make sure that this part is placed firmly
around the correct part of the cable. When
washing the vehicle, do not directly spray
water on to the rubber boots or scrub it
with brush. Use a dry cloth to clean this
area.
Check the installing condition of rubber
boots daily. After adjusting the free play
of throttle grip, never forget to place the
rubber boots to the original position.
If electrode is stained or clearance is not
right, satisfactory spark is not produced.
Clean and make adjustment.
●
Remove the spark plug cap.
●
Clean around the plug.
●
Using a plug wrench, remove the plug.
CABLE RUBBER PART
INSPECTION PART INSPECTION PART
RUBBER
●
Infiltration of the foreign materials or
water caused by damage of rubber
boots (disengagement, tearing, etc.)
may cause freezing in winter season
resulting in faulty operation. It may
lead death or serious injury by
decreasing of sudden acceleration and
braking force due to engine rpm.
●
If any damage is found, replace with
the new on immediately.
SPARK PLUG
SPARK PLUGSPARK PLUG CAP
RUBBER
LOCK NUT
To Next Page
