DAELIM B-BONE - Headlight; Passing Switch

14
<TURNING ON HEADLIGHT>
Put main switch key in “ON” position and
turn on headlight switch.
<DIMMER SWITCH>
High beam or low beam can be operated
by the use of dimmer switch.
HIGH BEAM
...... used when needing extra
light.
LOW BEAM
...... used when other vehicles
are present, in the city, etc.
When this switch is pressed, the headlight
flashes on to signal approaching cars or
when passing.
HEADLIGHT
CAUTION
● Use the high beam only in the
suburban road or when the usage of
the high beam not hinder the safe
driving of the car ahead.
DIMMER SWITCH
D
D
PASSING SWITCH
PASSING SWITCH
(LO)
(HI)
SWITCH POSITION FUNCTION
Headlight, taillight,
position lamp and
meter lights on.
Position lamp, taillight,
and meter lights on.
Light turned off.
(OFF)
(P)
(H)
HEADLIGHT SWITCH
