[Headlight Bulb]
① Turn the front under cover switch to
the right using the main switch key and
the front under cover will easily open.
② Remove the headlight maintance lid.
③ Remove the rubber cover.
④ Turn the socket clockwise, and remove
it.
⑤ Slightly press down on the bulb and
turn it counterclockwise.
⑥ Install a new bulb in the reverse order
of removal.
[Tail/stoplight Bulb]
① Loosen the pan screws and remove the
rear combination light lens.
② Loosen the tapping screw and remove
the tail/stop lens.
③ Slightly press down on the bulb and
turn it counterclockwise.
④ Install a new bulb in the reverse order
of removal.
39
MAIN SWITCH
KEY
FRONT UNDER
COVER
HEADLIGHT
MAINTANCE LID
RUBBER COVER
BULB
SOCKET
BULB
REAR COMBINATION LENS
TAPPING SCREW
TAIL & STOP LENS
PAN SCREW
