K1000896E Operation and Maintenance Manual Inspection, Maintenance and Adjustment 4-49
REPLACE OUTER AND INNER AIR CLEANER ELEMENTS
1. Replace inner element when outer element is replaced.
2. After removing outer element, remove wing nut and inner element.
3. Clean out inside of air cleaner housing. DO NOT use compressed air to blow out housing.
4. Install new inner element, and secure it into position with wing nut. DO NOT clean and reuse inner
element.
5. Install new outer element, and secure it into position with wing nut.
6. Install air cleaner cover.
NOTE: Make sure that all gaskets on wing nuts and cover are properly installed and seated.
CAUTION!
Never remove air cleaner element while engine is running. This will allow dirt to be sucked into
engine and cause serious engine damage. Always turn engine "OFF" before servicing air
cleaner.
