6
No. PART NAME PART CODE DESCRIPTION Q’TY SVC REMARK
A01 DRUM SUB AS 3617030010 D-M300 1 Y
A02 LIFTER WASH 361A401901 D-M300, PP 3 Y
A03 SPIDER AS 361A301610 D-M300 1 Y
A04 SPECIAL BOLT 3616063000 STS430 M6*21 SI-LOCK 3 Y
A05 DRAIN MOTOR AS
3919601110 DRAIN MOTOR AS NAKAGAW,220-240V-,50/60HZ, BV-DW23 2.5W 1 Y
DRAIN
MOTOR
ASSMBLY
66149-0005701-00 BE-3502A, NAKAGAW,220-240V-,50/60HZ, BV-DW23 2.5W 1 Y
A06 DRAIN HOUSING 36169-0000400-02 D-M300, FRPP, FILTER TYPE 1 Y
A07 CAP FILTER DRAIN
36109-0006400-01 CAP FILTER DRAIN D-M300, FRPP, FILTER TYPE
1 Y
36109-0006401-00 BE-3502A, D-M300, FRPP, FILTER TYPE
A08 PACKING CAP FILTER DRAIN 36196TC060 D-M300, NBR 40 1 Y
A09 HOSE AIR TRAP 3613276800 D-M300, EPDM 1 Y
A10 CLAMP HOSE 3611204700 ID27 2 Y
A11 AIR TRAP 361A500300 D-M300, PP 1 Y
A12 HOSE AIR 3613276900 D-M300, EPDM ID=4 OD=8, L=455 1 Y
A13 SENSOR PRESSURE 361482532A DL-DW12-H AIR INLET 270 HOOK TYPE 1 Y
A14 EMI FILTER 3611913100 DFC-2712D ,250V 12A, 1 Y OPTION
A15 FIXTURE HEATER 36119-0003300-00 SUS 304 0.7T 440X45 1 1 Y OPTION
A16 HEATER WASH
3612804011 230-240V.140MM.1400W.WIRE 1R0X350002.IRCA FUSE 2EA 1 Y 230-240V
3612804010 220V.140MM.1400W.TERMINAL 1R8A721.IRCA FUSE 2EA 1 Y 220V
3612804012 120V.140MM.1000W.WIRE 1R0X350007.IRCA FUSE 2EA 1 Y 120V
3612804013 110V.140MM.1000W.WIRE 1R0X350005.IRCA FUSE 2EA 1 Y 110V
A17 MOTOR BLDC
36189L8000 UNIT MOTOR BLDC DWD200BL(NEWMOTECH),DC 310V,125W,CL.F EARTH/T-X 1 Y
36189L8500 UNIT MOTOR BLDC GJ-2BA003A(GNJ),DC 310V,125W,CL.F,EARTH T-X 1 Y
66182-0012500 UNIT MOTOR BLDC PM92-20(TONLON), DC 310V,125W,CL.F EARTH/T-X 1 Y
A18 SPECIAL BOLT 3616067010 SPECIAL BOLT T/S-3 F/L 5*16 SEAL LOCK STS430 4 Y
A19 SPECIAL SCREW 7S422X4081 TT3 TRS 4X8 SE MFZN 2 Y
A20 BRACKET BODY 3610603500 SBHG1 T1.2 1 Y
A21 REATOR 3615800500 RT-028 L=3.6MH(0A),L=5.2MH(1A) 1 Y
A22 PCB PART(Y DIVIDER) 3612512900 D-M300, ATWD0404 1/4' DMT 1 Y
A23 HOSE INLET 3613270980-001 DFE04 LLDPE ID=4,OD=6 0.575 Y
A24 VALVE INLET
3615401000 AC 220~240V,50/60HZ, SV-11CWB-01,1WAY 2 Y
3615401120 120~127V,50/60HZ, SV-11CWB-27 1WAY, CHECK VALVE 2 Y
A25
TUB REAR SUB AS 3618831620 D-M300. TUB REAR+BEARING HOUSING 1 Y SVC_CODE
BEARING INNER 3616305900 D-M300,6203ZZ,ID=17,OD=40 1 Y
WATER SEAL 361A600900 D-M300,NBR ID=25,OD=50 1 Y
DRAIN HOUSING 36196TC010 DRAIN HOUSING D-M300, FRPP, FILTER TYPE 1 Y
BOND 2224050106 218W 0.005 N
A26 HOSE VENT 3613217940 D-M300 HOSE VENT AS 1 Y
A27 PULLEY 3618434300 D-M300, ALDC 1 Y
A28 SPECIAL BOLT AS 3616063110 M8X27 S/W P/W SI-LOCK HEX:13 1 Y
A29 BELT V 3616591700 BELT V M300/3PJ1031/GATES 1 Y
A30 HARNESS AS 66126-0014704-01
FULL OPTION Dong-Yang DWD-M301 CLAMP
CORE
1 Y
A31
WM PCB INVERTER
ASSY
PRPSSWDV09 D-M301 VE PCB AS, H/T, N-0.5W, 220V(CHINA ver.A#) 1 Y
40302-1032300-00 D-M301 VE PCB AS, H/T, N-0.5W, 220V(CHINA ver.q#) 1 Y
40302-1086300-00 D-M301 VE PCB AS, H/T, N-0.5W, 220V(CHINA ver.u#), ON-LINE 1 Y
40302-1086400-00
D-M301 VE PCB AS, H/T, N-0.5W, 220V(CHINA ver.J#),
OFF-LINE
1 Y
