Dahua D-VTO3311Q-WP User Manual

Quick Start Guide
10
Installation
If you do not want to install the rain cover, you could use the sticker included in the package to cover
the screw hole.
2.2.2 Villa Door Station (single button)
Here are examples of two model’s installation, depending on differences in model dimensions.
Model Example 1:
Open the port cover of the VTO, drill screw holes on the wall according to the dimension of
the mounting hole on the rear panel of the VTO.
Complete the cable wiring.
Fix the port cover to the rear panel of the VTO with four screws.
Fix the VTO on the wall with screws.

Dahua D-VTO3311Q-WP Specifications

General

Brand	Dahua
Model	D-VTO3311Q-WP
Category	Intercom System
Language	English
