Quick Start Guide
2
1.1.2 Rear Panel
The function ports might differ depending on the model.
Rear panel
Functional port
Table 1-2 Components
No. Name Function
1 SD card slot
Used to insert SD card so that data information such as
images and videos can be stored.
2 Functional ports
Alarm port, door detector port, 485 port, power port
and etc.
3 Network port RJ-485 network port to connect to the network.
4 Reset button
Press and hold the button for several seconds to do
factory reset.
