43
You also can go to System Config>Local Config>Talk Manager interface, to delete publish
info.
Figure 5-30
5.2.9 UPnP Setup
Note:
Visible when the device is set as SIP server.
Warning:
Login router, set router WAN port IP address connection to WAN.
Router enables UPnP function.
Connect device to router LAN port, to private network.
Via UPnP protocol create mapping relationship between private network and outer
network. Outer network user can visit device in LAN via outer IP address.
Step 1. Select System Config>UPnP Setup>General.
Step 2. Check “UPnP Enable” to enable UPnP function.
Step 3. Click Add. See Figure 5-31.
Figure 5-31
Step 4. Enable UPnP function, select enable, see chart below.
Parameter Note
Server
Name
Server name.
Protocol
