User’s Manual
7
Fix disk
Fix other disks on the bracket as needed.
Fix other disks
Fix the two drive brackets.
This is only need on models with 8 bays.
Fix drive brackets
Put the drive brackets back and fix them in the DVR.
Put back drive bracket
Connect the disks and the DVR with power cable and data cable.
