User’s Manual
198
Video Matrix
Select the check box to enable the function. When an alarm event
occurs, the video output port outputs the settings configured in "
Main
Menu > DISPLAY > Tour > Sub Screen
."
Not all models support this function.
The extra screen must be enabled to support this function.
Buzzer Select the check box to activate a buzzer noise at the Device.
Log Select the check box to enable the Device to record a local alarm log.
Alarm Tone Select to enable audio broadcast in response to a face detection event.
Click OK to save the settings.
Select the Enable check box, and then click Apply.
The tripwire detecting function is active. When the target object crosses the tripwire in the
defined direction, the system activates alarms.
Configuring Intrusion Rules
When the target enters and leaves the defined detection area, or the target appears in the defined
area, the system activates alarms.
You can define the shape and quantity of intrusion areas.
Supports detecting the behaviors that enter and leave the intrusion areas.
Supports detecting the behaviors that are moving in the intrusion areas. The quantity of areas
and lasting time can be configured.
Supports size filtering for target.
On the rule line that you added, in the Type list, select Intrusion.
Intrusion
Draw an area.
1) In the Channel list, select the channel that you want to configure the rules for.
2) Click .
