User's Manual
243
Figure 4-142
2) Configure the parameters. See Table 4-36.
Table 4-38
Parameter Description
Name Customize the rule name.
Action Set the intrusion action, including appear and crossing area.
Direction Set the direction to cross the area, including enter, exit and both.
Filter target
Click to filter the target. Check the blue wireframe and adjust the size
of the area with the mouse.
Each rule can set 2 target filters (maximum size and minimum size), that
is, when the passing target is smaller than the minimum target or larger
than the maximum target, no alarm will be generated. The maximum size
should not be smaller than the minimum size.
AI recognition
Select AI recognition and the system displays alarm target. The default
selection is person and motor vehicle and system automatically identifies
the person and motor vehicle appeared within the monitoring range.
3) Press and hold down the left button on the monitoring screen to draw the monitoring
area.
4) Click
OK
to complete the rule setting.
Step 3 Click , you can refer to "4.7.2.4.1 Tripwire" to set other parameters.
Step 4 Select
Enable
check box and click
Apply
to complete the intrusion setting.
