User's Manual
247
Figure 4-146
2) Set parameters. See Table 4-40.
Table 4-40
Parameter Description
Preset Select a preset you want to use IVS
Name Input customized rule name
Sensitivity
You can set alarm sensitivity. The value ranges from 1 to 10. The default
setup is 5.
Filter target
Click to filter the target. Check the blue wireframe and adjust the
size of the area with the mouse.
Each rule can set 2 target filters (maximum size and minimum size),
that is, when the passing target is smaller than the minimum target or
larger than the maximum target, no alarm will be generated. The
maximum size should not be smaller than the minimum size.
3) Draw a rule. Left click mouse to draw a zone, until you draw a rectangle, you can right
click mouse.
4) Click
OK
to complete the rule setting.
Step 3 Click , you can refer to "4.7.2.4.1 Tripwire" to set other parameters.
Step 4 Click
Apply
to complete the setup.
