User's Manual
289
Figure 4-181
Step 2 Configure the settings for the motion detection parameters. See Table 4-57.
Table 4-57
Parameter Description
Channel In the Channel list, select a channel to set the motion detection.
Region Click Setting to define the motion detection region.
Enable
Enable or disable the motion detection function. Check the box to
enable the function.
Sensitivity
The higher the value is, the easier it is to trigger an alarm. But at the same
time, the false alarm might occur. The default value is recommended.
Schedule Define a period during which the motion detection is active.
Anti-Dither
Indicates the time taken from the end of motion detection to the end of
alarm linkage action. The range is 0 to 600 seconds.
Alarm-out Port
The alarm device (such as lights, sirens, etc.) is connected to the alarm
output port. When an alarm occurs, the NVR device transmits the alarm
information to the alarm device.
Post-Alarm
When the alarm ends, the alarm extended for a period of time. The time
range is from 0 seconds to 300 seconds.
Show Message Check box to enable a pop-up message in your local host PC.
