User's Manual
379
Figure 4-266 Firewall
Step 2 Select
Enable
to enable firewall.
Step 3 Configure the parameters. See Table 4-87.
Table 4-87 Parameters
Parameter Description
Mode
Mode can be configured when Type is Network Access.
●
If Trusted Sites is enabled, you can visit device port successfully with
IP/MAC hosts in Trusted Sites.
●
If Blocked Sites is enabled, you cannot visit device port with IP/MAC
hosts in Blocked Sites.
Add
When Type is Network Access, you can configure IP Address, IP Segment
and MAC Address.
Type You can select IP address, IP segment and MAC address.
IP Address Enter IP Address, Start Port and End Port that is allowed or forbidden.
When Type is IP Address, they can be configured. Start Port and End Port
can be configured only in Network Access Type.
Start Port
End Port
