In Figure 3-115, click one HDD item, the S.M.A.R.T interface is shown as in Figure 3-116.
Figure 3-116
Parameter Function
SATA
1 here means there is 1 HDD.
For different series product, the max HDD amount may vary,
When HDD is working properly, system is shown as O. . “_” means there is
no HDD.
SN You can view the HDD amount the device connected to;
﹡ means the second HDD is current working HDD.
Type The corresponding HDD property.
Total space The HDD total capacity.
Free space The HDD free capacity.
Status HDD can work properly or not.
Bad track Display there is bad track or not.
Page up Click it to view previous page.
Page down Click it to view the next page.
View
recording time
Click it to view HDD record information (file start time and end time).
capability
Click it to view HDD property, status and etc,
117
