Figure 2-15
The redundant power series rear panel is shown as in Figure 2-16.
Figure 2-16
Please refer to the following sheet for detailed information.
SN Name SN Name
1 Alarm input/alarm output 2
HDMI portReserved port. Right now
system does not support HD decode
card.
3 Power port 4 HDMI port
5 eSATA port 6 USB port
22
