Daikin CTXG25K2VMW - Display Lens ASSY

Si041256 Display Lens ASSY
Removal Procedure 9
5. Display Lens ASSY
Warning

Be sure to wait for 10 minutes or more after turning off all power supplies before
disassembling work.
Step
Procedure Points
1
Remove the display
lens ASSY by turning it
counterclockwise.
2
Unfasten the hook and
remove the cover.
Display lens ASSY
(R12102)
(R12103)
Cover
