Si041256 Air Filters / Front Panel
Removal Procedure 3
3. Remove the front panel.
1
Open the front panel.
2
Release the front panel
locks on each side.
3
Remove the front panel.
Step
Procedure Points
(R12075)
(R12076)
Front panel lock
Right
(R12077)
Left
(R12078)
