Daikin CTXG25K2VMW - Page 8

Front Grille Si041256
6 Removal Procedure
6
Open the 2 screw
covers with a flat
screwdriver.
7
Remove the 4 screws.
8
Unfasten the 3 hooks
on the top of the front
grille.
9
Remove the front grille.
Step
Procedure Points
Screw cover
(R12089)
(R12090)
(R12092)
Front grille
(R12093)
