Daikin EBLA16DA3V3 Service Manual

5 | Maintenance
Service manual
312
EBLA09~16DA + EDLA09~16DA
Daikin Altherma 3 M
ESIE20-06A – 2021.03
Pipe
heater
Location Type PCB Connector Intermediate
connector
Control Energized when…
E6H Plate type
heat
exchanger
Aluminium
foil heater
Hydro
(A1P)
X2A +
X28A
X7M: 7‑8 Own bimetal
thermostat
(primary) +
contact KCR on
PCB (secondary)
Thermostat:
ON: T <4°C
OFF: T >9°C
KCR contact:
ON: outdoor T <5°C and
inlet water T <6°C
OFF: outdoor T >10°C or
inlet water T >11°C
E9H Expansion
vessel
Aluminium
foil heater
Hydro
(A1P)
X24A X7M: 1‑2 +
X13Y: 1‑2
Own bimetal
thermostat
ON: T <4°C
OFF: T >9°C
E10H Expansion
vessel flex
Tape
heater
Hydro
(A1P)
X24A X7M: 1‑2 +
X14Y: 1‑2
Own bimetal
thermostat
ON: T <4°C
OFF: T >9°C
E11H Water
inlet
Tape
heater
Hydro
(A1P)
X2A +
X28A
X7M: 3‑4 Contact KCR on
PCB
ON: outdoor T <5°C and
inlet water T <6°C
OFF: outdoor T >10°C or
inlet water T >11°C
E12H Water
outlet
after heat
exchanger
Tape
heater
Hydro
(A1P)
X2A +
X28A
X7M: 3‑4 Contact KCR on
PCB
ON: outdoor T <5°C and
inlet water T <6°C
OFF: outdoor T >10°C or
inlet water T >11°C
Pipe heater Power supply
voltage
Power Resistance Current
E6H 230VAC 50W 970Ω 0.23A
E9H 230VAC 50W 970Ω 0.23A
E10H 230VAC 16.6W 3300Ω 0.07A
E11H 230VAC 33W 1600Ω 0.15A
E12H 230VAC 33W 1600Ω 0.15A
