ESIE09-05 Test Operation
Test Operation 87
1.1.5 Check Operation
* During check operation, mount front panel to avoid the misjudging.
* Check operation is mandatory for normal unit operation.
(When the check operation is not executed, alarm code "U3" will be displayed.)
On completion of test operation, LED on outdoor unit PC board displays the following.
H3P ON: Normal completion
H2P ON: Abnormal completion →Check the AHU remote controller for
abnormal display and correct it.
Check on operation
(V3057)
Press and hold the TEST
OPERATION button (BS4) on
outdoor unit PC board for 5
seconds.
Set to setting mode 1 (H1P led is
o) (refer to "Setting mode 1")
The test operation is started automatically.
The following judgements are conducted within 15 minutes(about 30
minutes at the maximum).
“Check for wrong wiring”
“Check stop valve for not open”
“Check of refrigerant charge”
“Pipe length automatic judgement”
The following indications are conducted while in test operation.
LED lamp on outdoor unit PC board H2P ickers (test operation)
Remote controller Indicates “TEST OPERATION” on lower left.
