Specifications SiUS091601EA
15 Part 2 Specifications
Model Indoor Unit FTX12NMVJU FTX15NMVJU
Outdoor Unit RXL12QMVJU9 RXL15QMVJU
Cooling Heating Cooling Heating
Power Supply 1 , 60 Hz, 208 - 230 V 1 , 60 Hz, 208 - 230 V
Capacity Rated (Min. ~ Max.) kW 3.20 (1.30 ~ 3.90) 4.00 (1.30 ~ 5.50) 4.40 (1.70 ~ 5.40) 5.35 (1.70 ~ 7.20)
Btu/h 10,900 (4,400 ~ 13,300) 13,600 (4,400 ~ 18,800) 15,000 (5,800 ~ 18,400) 18,300 (5,800 ~ 24,600)
kcal/h 2,750 (1,120 ~ 3,350) 3,440 (1,120 ~ 4,730) 3,780 (1,460 ~ 4,640) 4,600 (1,460 ~ 6,190)
Moisture Removal gal/h 0.45 — 0.63 —
Running Current (Rated) A 4.36 - 3.94 5.10 - 4.61 5.92 - 5.35 6.81 - 6.16
Power Consumption Rated (Min. ~ Max.) W 870 (280 ~ 1,390) 1,025 (240 ~ 1,660) 1,150 (290 ~ 1,630) 1,340 (390 ~ 2,310)
Power Factor (Rated) % 96.0 - 96.0 96.7 - 96.7 93.5 - 93.5 94.6 - 94.6
COP Rated (Min. ~ Max.) W/W 3.68 (4.64 ~ 2.80) 3.90 (5.42 ~ 3.30) 3.82 (5.86 ~ 3.30) 4.00 (4.36 ~ 3.12)
EER Rated (Min. ~ Max.) Btu/h·W 12.5 (15.7 ~ 9.6) 13.3 (18.3 ~ 11.3) 13 (20 ~ 11.3) 13.7 (14.9 ~ 10.6)
SEER / HSPF 20.0 12.0 20.0 13.0
Piping
Connections
Liquid in. (mm) 1/4 ( 6.4) 1/4 ( 6.4)
Gas in. (mm) 3/8 ( 9.5) 1/2 ( 12.7)
Drain in. (mm) 5/8 ( 16.0) 5/8 ( 16.0)
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length ft (m) 65-5/8 (20) 98-1/2 (30)
Max. Interunit Height Difference ft (m) 49-1/4 (15) 65-5/8 (20)
Chargeless ft (m) 32-13/16 (10) 32-13/16 (10)
Amount of Additional Charge of
Refrigerant
oz/ft
(g/m)
0.21 (20) 0.21 (20)
Indoor Unit FTX12NMVJU FTX15NMVJU
Front Panel Color White White
Airflow Rate H
cfm
(m³/min)
434 (12.3) 413 (11.7) 593 (16.8) 653 (18.5)
M 311 (8.8) 321 (9.1) 505 (14.3) 554 (15.7)
L 247 (7.0) 258 (7.3) 431 (12.2) 470 (13.3)
SL 145 (4.1) 219 (6.2) 367 (10.4) 399 (11.3)
Fan Type / Motor Output W Cross Flow Fan / 28 Cross Flow Fan / 33
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A 0.28 - 0.25 0.25 - 0.23 0.23 - 0.21 0.25 - 0.23
Power Consumption (Rated) W 31 - 31 28 - 28 33 - 33 38 - 38
Power Factor (Rated) % 53.2 - 53.9 53.8 - 52.9 69.0 - 68.3 73.1 - 71.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 11-1/4 × 30-5/16 × 8-3/4 (285 × 770 × 223) 11-5/8 × 39 × 10-3/8 (295 × 990 × 263)
Packaged Dimensions (H × W × D) in. (mm) 14-3/16 × 32-11/16 × 12 (360 × 831 × 305) 14-9/16 × 42-1/2 × 15-3/8 (370 × 1,080 × 390)
Weight (Mass) Lbs (kg) 18 (8) 27 (12)
Gross Weight (Gross Mass) Lbs (kg) 25 (12) 37 (17)
Sound Pressure
Level
H / M / L / SL
dB(A) 45 / 37 / 30 / 19 45 / 37 / 30 / 26 45 / 41 / 36 / 33 45 / 41 / 37 / 33
Outdoor Unit RXL12QMVJU9 RXL15QMVJU
Casing Color Ivory White Ivory White
Heat Exchanger Fin / Spec. Tube Waffle Fin (PE) / 7 mm Hi-XD Tube Waffle Fin (PE) / 7 mm Hi-XD Tube
Compressor Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC36PXD 2YC36PXD
Motor Output W 1,100 1,100
Refrigerant Oil Type / Charge oz (L) FVC50K / 21.5 (0.650) FVC50K / 21.5 (0.650)
Refrigerant Type / Charge Lbs (kg) R-410A / 2.09 (0.95) R-410A / 3.20 (1.45)
Airflow Rate H
cfm
(m³/min)
1,144 (32.4) 1,006 (28.5) 2,044 (57.9) 2,044 (57.9)
SL 865 (24.5) 777 (22.0) 1,762 (49.9) 1,585 (44.9)
Fan Type / Motor Output W Propeller / 20 Propeller / 71
Running Current (Rated) A 4.08 - 3.69 4.85 - 4.38 5.69 - 5.14 6.56 - 5.93
Power Consumption (Rated) W 839 - 839 997 - 997 1,117 - 1,117 1,302 - 1,302
Power Factor (Rated) % 98.9 - 98.9 98.9 - 99.0 94.4 - 94.5 95.4 - 95.5
Starting Current A 4.94 6.81
Dimensions (H × W × D) in. (mm) 21-5/8 × 26-9/16 × 11-3/16 (550 × 675 × 284) 28-15/16 × 34-1/4 × 12-5/8 (735 × 870 × 320)
Packaged Dimensions (H × W × D) in. (mm) 24-3/4 × 32-11/16 × 16 (629 × 830 × 407) 31-7/8 × 41-9/16 × 18-1/4 (810 × 1,056 × 464)
Weight (Mass) Lbs (kg) 70 (32) 108 (49)
Gross Weight (Gross Mass) Lbs (kg) 80 (36) 123 (56)
Sound Pressure Level H dB(A) 50 50 50 55
Conditions Based on Indoor ; 80°FDB
(26.7°CDB) / 67°FWB
(19.4°CWB)
Outdoor ; 95°FDB (35°CDB)
/ 75°FWB (24°CWB)
Piping Length: 25 ft (7.5 m)
Indoor ; 70°FDB (21°CDB) /
60°FWB (15.6°CWB)
Outdoor ; 47°FDB
(8.3°CDB) / 43°FWB
(6°CWB)
Piping Length: 25 ft (7.5 m)
Indoor ; 80°FDB
(26.7°CDB) / 67°FWB
(19.4°CWB)
Outdoor ; 95°FDB (35°CDB)
/ 75°FWB (24°CWB)
Piping Length: 25 ft (7.5 m)
Indoor ; 70°FDB (21°CDB) /
60°FWB (15.6°CWB)
Outdoor ; 47°FDB
(8.3°CDB) / 43°FWB
(6°CWB)
Piping Length: 25 ft (7.5 m)
Drawing No. C: 3D123801 C: 3D101716
Notes SL: The quiet fan level of the airflow rate setting. SL: The quiet fan level of the airflow rate setting.
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
