Wired Remote Controller SiUS091601EA
33 Part 3 Printed Circuit Board Connector Wiring Diagram
3. Wired Remote Controller
3.1 BRC1E73
Wired Remote
Controller PCB
1) P1, P2 Terminal for indoor unit
2) R4T Room temperature thermistor
P2
R4T
P1
2P298037-7
