Field Settings for FDMQ Series SiUS091601EA
213 Part 7 Trial Operation and Field Settings
5.2 Overview of Field Settings
The Second Code No. is factory set to "01".
Do not use any settings not listed in the table.
For group control with a wireless remote controller, initial settings for all the indoor units of the
group are equal.
For group control, refer to the installation manual attached to the indoor unit for group control.
External Static
Pressure Settings
12 class
Mode
No.
First
Code
No.
Second Code No.
Description of setting
01 02 03
10
(20)
0
Light
Approx.
2,500 hrs.
Heavy
Approx.
1,250 hrs.
—
Filter cleaning sign interval (used to
change filter cleaning display
interval according to filter
contamination)
Longlife filter
Approx.
200 hrs.
Approx.
100 hrs.
—
Standard
filter
3 Display No display —
Filter cleaning sign (used to set filter cleaning display
ON/OFF)
11
(21)
7OFF
Air volume
adjustment
completion
Air volume
adjustment start
Air volume adjustment
Factory Setting
Mode
No.
First
Code
No.
Second Code No. External static pressure
13
(23)
6
03 30 Pa
04 40 Pa
05 50 Pa
06 60 Pa
07 70 Pa
08 80 Pa
09 90 Pa
10 100 Pa
11 110 Pa
12 120 Pa
13 130 Pa
14 140 Pa
15 150 Pa
Factory Setting
