Daikin FDMQ-R Series Service Manual

SiUS091601EA Piping Diagrams
Part 8 Appendix 222
FVXS09/12NVJU FVXS15NVJU
FDMQ12/18/24RVJU
INDOOR UNIT
MUFFLER ASSY HEAT EXCHANGER
1/4 CuT
9/32 CuT
1/4 CuT
1/4 CuT
1/4 CuT
M
FAN MOTORTURBO FAN
1/4 CuT
3/8 CuT
FIELD PIPING
(1/4 CuT)
FIELD PIPING
(3/8 CuT)
THERMISTOR
ON HEAT EXCH.
REFRIGERANT FLOW
COOLING
HEATING
4D091794
INDOOR UNIT
MUFFLER ASSY HEAT EXCHANGER
1/4 CuT
9/32 CuT
1/4 CuT
1/4 CuT
1/4 CuT
1/4 CuT
M
1/4 CuT
FAN MOTORTURBO FAN
1/4 CuT
3/8 CuT
REFRIGERANT FLOW
COOLING
HEATING
FIELD PIPING
(
1/4 CuT
)
FIELD PIPING
(
1/2 CuT
)
THERMISTOR
ON HEAT EXCH.
4D091795A
C: 4D112974A
FDMQ12RVJU 1/4 (6.4)
FDMQ18RVJU
FDMQ24RVJU
MODEL
1/4 (6.4)
1/4 (6.4)
3/8 (9.5)
1/2 (12.7)
5/8 (15.9)
