FTX-N/U, FVXS-N, FDMQ-R Series EDUS091558E
193
C: 3P379751-4C
6
Read Before Operation
Outdoor Unit
• The appearance of the outdoor unit may differ between different models.
 Open the front panel
Refrigerant pipes and
inter-unit wire
Ground terminal (inside)
Drain hose
Air outlet
Model name
Air inlet
(back and side)
Outdoor temperature
sensor (back)
Titanium apatite
deodorizing fi lter
(without frame)*
*FTXN09/12NMVJU: Sold separately.
Air fi lter
