Read Before Operation
Outdoor Unit
 Open the front panel
Refrigerant pipes
Inter-unit wire
Ground terminals
(inside)
Drain hose
Air inlet
(back and side)
Air outlet
Outdoor temperature
sensor (back)
Model name
Air lter
Titanium apatite
deodorizing lter
