Daikin FTYN35GXV1B - Page 77

Indoor Unit SiBE01-829
66 Removal Procedure
5
Remove the horizontal
blade.
2. Removing the safety net
1
Unfasten the hooks at
the lower part with a flat
screwdriver.
2
Unfasten the hooks at
the upper 2 positions.
3
Remove the safety net
toward yourself.

Repeat the same procedure
to remove the safety net on
the other side.
Step Procedure Points
(R8582)
(R8583)
(R8584)
(R8585)
