Table 50 continued: Unit Conguration Menu
Conguration
Code Position
Description Values (Default in Bold) Special Condition RTU MPS DPS DPS_H SCU
5
Generic Condenser Stages/
VFD Comp Cfg
1 – 8 Stages (default = 8)/ 0=NA
● ●
(if 4=4, 5or 6)
●
(if 4=4, 5or 6)
1=Single
2=Tandom
3=Trio
6 Low Ambient
0 = No
This position currently
has no effect on unit
operation.
1 = Yes
7 Condenser Control
0=Std Method 1 ● ● ● ●
1=Std Method 2
2=Evap ABB
3=Evap MD2
4=Evap MD3
5=Evap DF
6=Not Used
7=EBM
8=INV
9=INV w/MicroC OA Coil
8 Damper Type
0=None
Values 1, 2, 5 & 7
only apply if
Position 1 = 0 (RTU),
2 (MPS), 3 or 4 (DPS)
Value 4 only applies if
Position 1 = 1 (SCU)
● ● ● ● ●
1=Single Position 30%
2=Single Position 100%
3=Economizer Airside
4=Economizer Waterside
5=100%OA_D3
6=AirEcon_D3
7=30%_DOAS
8=EconoAirsideFDD
9=D3EconFDD
9 OA Flow Station
0=None
● ● ● ● ●
1=DF_015-030 (800)
2=DF_036-042 (802)
3=DF_045-075 (047)
4=DF_080-135 (077)
5=Generic Flow Station
6=Generic Flow Station w/CO2
7=Ebtron MB
10 Heating Type
0=None
● ● ● ● ●
1=F&BP Control
2=Staged
3=Modulated Gas, 3-1
4=Modulated Gas 20-1
5=Steam or Hot Water
6=SCR Electric
7=MPSLoGas
8=MPSHiGas
11 Max Heating Stages 1-8 Stages (Default = 1) ● ● ● ● ●
12, 13, 14 Max Heat Rise Three Digits (Default = 100) ● ● ● ● ●
15 Supply Fan Type
0=Constant Volume
● ● ● ● ●
1=VFD/ABB
2=VFD/DF
3=VFD/MD2
4=VFD/MD3
5=VFD/MD6
6=EBMVAV
7=EBMCAV
16 Return Fan Type
0=CAV
● ● ● ●
1=RF_EF VFD/ABB
2=RF_EF VFD/DF
3=RF_EF VFD/MD2
4=RF_EF VFD/MD3
5=RF_EF VFD/MD6
6=PrpEx VFD/ABB
7=PrpEx VFD/DF
8=PrpEx VFD/MD2
9=PrpEx VFD/MD3
A=PrpEx VFD/MD6
B=None
C=1StageExh
D=2StageExh
E=3StageExh
F=EBMVAV
G=EBMCAV
