Table 50 continued: Unit Conguration Menu
Conguration
Code Position
Description Values (Default in Bold) Special Condition RTU MPS DPS DPS_H SCU
17
Return/Exhaust Fan Capacity
Control Method
0=None
● ● ● ●
1=Tracking
2=Building Pressure
3=Speed
4=OADamper
18 Second Duct Pressure Sensor
0=No
● ●
1= Yes
19 Entering Fan Temp Sensor
0=No
● ● ● ●
1=Yes
20 Energy Recovery
0=None
● ● ● ●
1=ConstSpdWhl/NoRH
2=VarSpdWhl/Danfoss
3=VarSpdWhl/MD2
4=VarSpdWhl/MD3
5=VarSpdWhl/ABB
6=ConstSpdWhl/wRH
21 Cooling Circuit Type
0=Individual
Values 0 and 1
are valid only when
Position 1 = 1 (SCU)
● ● ●
1=2,3 or 4 Circ. Water Condenser
2=2 Circ. Air Condenser
22 Head Pressure Control
0=No This position
is valid only when
Position 1 = 1 (SCU).
●
1=Yes
23 Bypass Valve Control
0=Slave This position
is valid only when
Position 1 = 1 (SCU).
●
1=Bypass
24, 25, 26 Unit Size Three digits (default 050) ● ● ● ● ●
27 Refrigerant Type
0=R22
● ● ● ● ●
1=R407C
2=R410A
28 Reheat Type
0=None
● ● ● ●
1=StgHG
2=ModHG
3=StdHtRht
4=ModLSC
5=ModHG&LSC
29 Unit Voltage
0=208/60Hz
● ● ● ● ●
1=230/60Hz
2=460/60Hz
3=575/60Hz
4=208/50Hz
5=230/50Hz
6=460/50Hz
7=575/50Hz
30 EVType
0=None
● ●
1=EVB_Sag
2=EVB_DF
3=MTIII_Sag
4=MTIII_DF
5=MTIII_Sag_DF
6=MTIII_DF_Sag
Alarm Lists Menu
The Alarm Lists Menu is also available from the Service Menu
and is described on page 62.
