The transportation stay for protecting the unit during transport must be removed.
Proceed as shown in the figure and procedure below.
1 Remove the bolt (a) and washers.
2 Remove the transportation stay (b) as shown in the figure below.
1
2
a
b
a Bolt
b Transportation stay
