14 | About the box
Installer and user reference guide
55
RXYSA8~12AMY1B
VRV 5-S system air conditioner
4P752782-1A – 2024.02
±134
kg
8HP
±163
kg
10+12HP
14.3 To remove the accessories from the outdoor unit
1 Remove the service cover. See "17.2.2To open the outdoor unit"[483].
2 Remove the accessories.
8 HP 10+12 HP
a
1×
b
1×
c
1×
d
1×
2× (8 HP)
3× (10+12 HP)
1×
f g h i
1×1×
e
2×
a General safety precautions
b Outdoor unit installation and operation manual
c Multilingual fluorinated greenhouse gases label
d Installation information leaflet
e Declaration of conformity
f Fluorinated greenhouse gases label
g Gas piping accessory1 (only for 10HP:Ø19.1mm)
h Gas piping accessory2 (8HP:Ø19.1mm; 10+12HP:Ø22.2mm)
i Cable tie (8HP:2×; 10+12HP:3×)
14.4 To remove the transportation stay
NOTICE
If the unit is operated with the transportation stay attached, abnormal vibration or
noise may be generated.
