121.1
3075
14.2
361
L
T
Y
X
"A"
2.0
51
29.0
.875 DIA MOUNTING HOLES (4)
737
13.0
330
23.5
597
Z
*333611621* p. 3 of 4
CERTIFIED, WGZ070-130D
MICROTECH II USER INTERFACE
CIRCUIT 2
CIRCUIT 1
CONDENSER
RELIEF VALVES
VENT
OUTLET
INLET
DRAIN
NOTE: CONDENSER
WATER CONNECTIONS
COULD BE ON OPPOSITE
END IF ORDERED AS LH.
4.0
102
6.0
152
POWER
CONNECTIONS
.88 KNOCKOUTS
REMOVABLE
DISC. HANDLE
CONTROL
CONNECTIONS
.88 KNOCKOUTS
ON OPPOSITE SIDE
REMOVE BRKT.
FOR SHIPPING
ONLY
EVAPORATOR
INLET
OUTLET
40.0
1016
56.4
1434
34.1
866
17.9
454
10.0
253
32.0
813
20.0
508
14.5
369
65.5
1664
35.2
894
40.2
1022
32.6
827
MAXIMU M
OVERALL
LENGTH IN(MM)
CONDENSER WATER
CONNECTION IN(MM)
VICTAULIC
L SIZE (NOM) A SIZE (NOM) T X Y Z
149 3 8.8 4 13.8 64.2 29.5 15
(3785) (76) (224) (102) (351) (1631) (749) (381)
149 3 8.0 4 13.8 67.2 32.6 16
(3785) (76) (203) (102) (351) (1707) (828) (406)
149 3 6.0 4 13.8 69.2 35.4 17
(3785) (76) (152) (102) (351) (1758) (899) (432)
148 3 3.1 4 12.9 68 35.6 17
(3759) (76) (79) (102) (328) (1727) (904) (432)
149 3 1.0 4 13.7 67.7 36.1 17
(3785) (76) (25) (102) (348) (1720) (917) (432)
CHILLER WATER
CONNECTION
IN(MM) VICTAULIC
CENTER OF
GRAVITY
WGZ130D
WGZ080D
WGZ
MOD EL
NUMBER
WGZ090D
WGZ100D
WGZ115D
