Daintree
™
Controls
|
WHS20/WHR1 User Manual
|
V1.0
Modifying Occupancy Detection Settings for a Profile
From the Main Menu:
1. Click UP/DOWN to highlight “View or Edit Saved Profile” and click RIGHT to select.
2. Click UP/DOWN buttons to highlight profile that you would like to modify.
3. Click RIGHT button to go in and edit that profile
Once in the Daintree One Profile menu:
4. Click DOWN button to highlight “Occupancy Detection”
5. Click RIGHT button to edit the Occupancy Detection settings
Once in the Occupancy Detection menu:
6. Edit desired settings based on definitions above (using UP/DOWN/RIGHT/LEFT /CENTER buttons)
7. Once you have changed all of the settings you would like, click the LEFT button to go one menu level up
(back to the Daintree One Profile menu screen)
Once, you are back in the Daintree One Profile menu:
8. Click the DOWN button until “Send” is highlighted yellow.
9. Click the RIGHT button while “Send” is highlighted.
10 Point the WHR1 at the WHS20 sensor on the LED fixture and click the CENTER button to send.
11 If multiple devices were detected, use UP/DOWN buttons to highlight the desired device and then press
RIGHT button to select.
1 The message shows that the profile was sent successfully.
1
4
5
6
8
10
12
7
9
11
2
3
